Vertical Dial on Village House . Marnhull . Dorset
The dial is above the front door of a house in the village, with a stone ledge above it. It doesn’t give the impression of being old. There is little sign of weathering or erosion and the incisions are all equally clean. BSS gives it as C18?? and suggests it may be a replacement for an earlier dial. Given the design, I wonder if it is actually a modern C20 direct copy of the original?
The dial is canted to face south and provide an accurate reading. Noon is marked, as often, by a cross. The archaic use of IIII for IV might also suggest a careful copy of an old dial, as may the flourishes in the lower corners.
Vertical Dial on Village House . Marnhull . Dorset
GSS Category: Vertical Dial; Canted Dial; Dial on house
GRADE I † C13 nave, chancel, S porch inc outer archway. C15 alterations & additions – chapel, tower. Restored 1885. 2 Purdue bells. 4m W of Sherborne and E of Yeovil. 50.9532 / -2.5732 / ST598172
DIALS
There are 3 dials beside the porch doorway, 1 on the left side and 2 on the right. The intricacies of the dials are clearer from the BSS archive photos and diagrams compared with my photos, taken in bright sunlight and not picking up the details.
DIAL 1
South Porch L of doorway. 13 lines, with the noon line extended, and 23 pocks. The diagram suggests 1, perhaps 2, mid-morning Mass markers. GLP points out that the lines are below the horizontal whereas almost all the pocks are above it; and that the design is accurate.
St Nicholas . Nether Compton . Dorset – Scratch Dial 1
DIAL 2
South porch R of doorway. Despite the extended ‘noon line’ (as it appears), the dial must in fact be upside down. If not, it can’t have had any practical use. 10 lines with very variable angles and 12 pocks. GLP describes it as crudely cut as a tide / octaval dial. The white item is a stone, which was in place when I originally saw the dial, and still 18m later. I left it in peace.
St Nicholas . Nether Compton . Dorset – Scratch Dial 2
DIAL 3
A semi-circular dial with 13 lines, almost all of which end pocks. There is a complete inner circle round the gnomon hole, with semi-circle outside it. GLP found the dial to be accurately cut.
St Nicholas . Nether Compton . Dorset – Scratch Dial 3
On chancel—(a) on external S. wall, W. of S. window; on N. chapel—(b) on N. external wall, W. of N.E. window, reset; on nave—(c) on external N. wall, between N.E. window and doorway; (d) on E. splay of N. doorway; (e and f) on E. jamb of S. doorway, two crosses; (g) on E. splay of S. doorway; (h) on E. splay of S.W. window; on W. face of tower— (i) against N. buttress; all formy crosses in circles except second on jamb of S. doorway, mediæval (BLB)
St Nicholas . Nether Compton . Dorset – Consecration Cross
GSS Category: Scratch Dial; Consecration Cross
All photos Keith Salvesen + BSS archive (also diagrams)
GRADE II* † Built 1776. A fine, uncomplicated Georgian building externally; restored and much remodelled internally 1890s by Temple Moore. ‘Urbane and assured‘PEV. Original clock on the bell tower replaced by a memorial sundial dated 19†18. Selected for the cover image for Cumbria in Pevsner’s Buildings of England series. 8m N of Longtown. 55.0386 / -2.9543 / NY391719
Kirkandrews . Cumbria . Walter Baxter Geo
DIAL
This handsome church has a moving story to tell. The tower originally had a clock. In 1918, this was replaced by a commemorative sundial to honour the two sons of the Graham family from nearby Netherby, after their safe return home from WW1.
The dial has an inscription around the circumference that reads in two parts, and a Motto
FOR OUR TWO DEAR SONS FFG & RPG WHO LIVED TO COME HOME FROM THE GREAT WAR THANKS BE TO GOD ALONE
LUX POST UMBRAM
The motto and its sentiments are self-explanatory. The same – or very similar – formula has been noted in northern Italy MG; and (I notice) for abstract art works that contain both light and shadow…
DIAL
The dial has an attractive design marking hours and 1/2 hours from 6 round 5. It appears to be hand-painted rather than machine made. The robust gnomon casts a clear shadow that also benefits sheep, cows, and salmon-fishermen in season.
Kirkandrews . Cumbria . Walter Baxter Geo
GSS Category: Vertical Dial; Sundial Motto; Memorial Mottos
Credits: Keith Salvesen; Walter Baxter dial close-up Geo ; Alun Bull English Heritage PEV; Yale University Press (cover image)
All Saints . Rothbury . Northumberland (C of E Heritage Record / Dave Evans)
ALL SAINTS . ROTHBURY . NORTHUMBERLAND
GRADE II* † On Pre-Conquest / Anglo-Saxon site. C13 / C14, rebuilding & restoration C19 in similar style. Located in Coquetdale with linked churches. 12m SW of Alnwick, close to NT Cragside. 55.309 / -1.9106 / NU057016
DIALS
There are 2 dissimilar scratch dials on the church, and an intriguing cube dial (shown below and will feature as a separate post in the Cube Dial section) on the ground in the Churchyard.
DIAL 1
Located on the E-most buttress of the S wall of the chancel. Quite a large dial centred in its stone, with a blocked gnomon hole. There are 16 lines, encircled and fairly evenly spaced. This makes the dial out of kilter with the normal time interludes. BSS notes that instead of the 15º angles usual for this type of dial with 24 lines, they are more like 22º here.
Between the 2 E-most buttresses of the S wall of the chancel. Only 3 lines radiate from the filled gnomon hole (incomplete quadrant markings): the horizontals (6-to-6) and a shorter noon line. BSS notes that in 1903 a vertical line above the hole was recorded, and so the design once had 4 quarters / sectors. The dial is contained within a double circle.
The Parish of Upper Coquetdale has an interesting page about All Saints, its history, and its various features HERE
Pendulum Publications has an excellent and detailed article about the Rothbury Dials – including the C18 cube – HERE Highly recommended if you want to investigate this church and its dials further, and medieval ‘clocks’ generally. It was originally published in Clocks Magazine of November 1991.
All Saints . Rothbury . Northumberland – Keith Bates / Clocks Magazine 1991; Pendulum Publications
GSS Category: Scratch Dial; link to Cube Dial
Image Credits: Erika Clarkson for the photos from her visit; others as captioned
A sundial on the terrace of this fine house, with its C17 origins and unbroken line of Digbys. The renowned gardens are especially worth visiting in Spring. It features a collapsible gnomon, an unusual feature not conducive to enhancing its primary purpose.
GRADE I † C13 origins: masons’ marks on the fabric date from C13 and are identical with some found at Wells cathedralBHO. Development mainly C15 (tower) and C16, with C19 work by Wyatt and later attention. Poulett family much in evidence. Good graffiti / protection marks. Fine gilded weathercock dated to 1756. 4m N of Crewkerne . 50.9107 / -2.8286 / ST418126
DIAL
Hinton St George Church . Som – Scratch Dial
A single scratch dial tucked away on the W side of a buttress, and of doubtful value as a time marker, both for position and orientation. There are 4 lines with terminal pocks on the left side; and a single pock at the top (ie midnight). The gnomon hole, already quite big, has been crudely enlarged – and quite recently, by the look of it.
Hinton St George Church . Som – Scratch Dial
An explanation for the unpromising location and the unsatisfactory design is that the dial was relocated at some stage, perhaps when the tower was built (and the buttress added?). It is far from unusual for a dial reused in this way to be inverted, as if decommissioning it. An inversion of the image above makes far more sense, with the noon line marked by a single pock, and the radials to its right. An afternoon dial.
Hinton St George Church . Som – Scratch Dial (inverted)
GRAFFITI & APOTROPAIC SYMBOLS / PROTECTION / MARIAN MARKS
Graffiti & Apotropaic Symbols / Protection Marks / Marian VV Marks
GRADE I † The Church forms part of the Boconnoc Estate and has no Dedication*. Probably C12 origins as the Manor Chapel; gradual development; restored 1873. Now in the care of the Cornwall Historic Churches Trust. 10 m SW of Liskeard. 50.4159 / -4.6099 / SX146605
DIAL
The time-worn dial is set into the apex of the porch and canted westwards. Dated 1716, it is also inscribed with a set of 3 double initials RC, DT, & TG. ‘RC’ is in a different style, and the date – perhaps significantly – is below the two other pairs of initials. Possibly the latter installed the dial in honour of the former.
The dial shows 1/4 as well as 1/2 hours. The 12 of noon is replaced by a cross. IIII is used for IV. The gnomon is presumably not original, but has clearly been in situ for a considerable time.
Boconnoc Parish Church – Sundial dated 1716
* Sadly no St Boconnoc is listed in the Ox. Book of Saints)
GSS Category: Vertical Dial. Old (post medieval) Dial
ST MARY † Grade 1. Early C13, alterations c.1500, N transept added C19. Between Sherborne & Marston Magna, on the Som. / Dorset boundary. Scratch dials, vertical dial, porch graffiti and protection (‘witch’) marks. 50.9948 / -2.5565 / ST610218
St Mary . Rimpton . Som. – Vertical Dial
Quite a while ago I wrote (in 2 parts) about the 4 main medieval scratch dials at the church. The links are below. I recently revisited St Mary for a further look at the dials (there are a couple of others to write up) as well as some interesting church marks including a small hexfoil within the porch. A revised single post featuring all of the above will emerge in due course.
DIAL
I also photographed the Vertical Dial for BSS records. It is located on the end merlon of the parapet, easily visible. It has a simple, almost square face. The plain metal gnomon is fixed into the top of the dial stone, and into the mortar line under the stone below it.
There are other unmarked (no lines, pocks, numerals) dials in the S Somerset / W Dorset region and I though this was one. However, later examining the main photograph in the gallery below, I detected 2 faint lines in U L quadrant that seem deliberately cut. There’s a ghost of a line on the opposite side. So possibly this was once a conventionally marked dial that has slowly and very evenly eroded.
It is hard to date. The dial stone differs from the ones around it. At a guess, it was added C19, perhaps when other work was carried out (eg adding the N transept). BHO notes that in 1827 the church was ‘repaired and beautified’. Perhaps adding the dial was part of that process.
St Nicholas . Dinnington . Som. (Geo / Sarah Smith )
ST NICHOLAS . DINNINGTON . SOMERSET
GRADE II † Established C12, first recorded 1207; mostly C15; restoration 1863. C13 (?) font. Originally the chapelry to nearby Seavington St Mary. Very pretty, both the building and the dial. 5m NW of Crewkerne. 50.9113 / -2.8505 / ST403127
DIAL
St Nicholas . Dinnington . Som. – Scratch Dial
DEH visited in August 1915 and added a note to his often largely measurement-based record.
There is a full complement of 24 lines, with areas of erosion, radiating from the gnomon hole in the centre of the dial stone. I am not clear which added lines DEH refers to. I infer that the dial may have been a hemisphere marking dawn to dusk only from the horizontal 6-to-6 lines. Then perhaps for reasons of aesthetics / symmetry an upper hemisphere was cut to match it.
St Nicholas . Dinnington . Som. – Scratch Dial and 180º rotation
There’s another conundrum concerning the 4 terminal pocks in UR quadrant (above). If the dial is in its original position (L), they would have been useless and indeed pointless. But if the dial stone was at some stage at 90º or (more likely and convincingly) 180º from its present position, they would be effective as daytime Mass markers. In the rotated image (R), the pocks are in the right place to emphasise forenoon Mass.
GSS Category: Scratch Dial; Mass Dial
All photos: Keith Salvesen, except header image Sarah Smith / Geo /
DEDICATION † ST ANDREW . Parish church. Late C13, consecrated 1312, completed C15, restoration from C19. A ‘major church’PEV. A good place to find out more is the RCHM entry ST ANDREW YETMINSTER. Carefully compiled church and Parish Archive. 10 Consecration Crosses from medieval to (relatively) modern. An important very early (1683) clock, now in restoration (see below).
LISTING † Grade 1
LOCATION † 5 miles SW of Sherborne, / SE of Yeovil. Noteworthy village easily accessed. Fine vernacular Ham stone buildings give the feel of an earlier era. Many listed buildings. Village also highly regarded by PEV. Station in village (not, as elsewhere locally, a wayside halt). Etiminstre in DB 50.8939 / -2.578 / ST594106
DIALS † Two dials on the buttress E. of S door, both C15
DIAL 1
A semicircle dial with 13 lines (including the horizontal). BSS notes no circumferential circle. The noon line is extended, and 4 others end slightly beyond the circumference . GLP describes it as very neat and accurately marked. Both dials have been thoroughly examined – clips of the original records from the excellent church archive are below.
St Andrew . Yetminster . Dorset – Scratch Dial 1
St Andrew . Yetminster . Dorset – Scratch Dial 1St Andrew . Yetminster . Dorset – Scratch Dial 1
DIAL 2
An unusual rather drooping design, explained below. Gnomon hole in the mortar line. The dial is split across 2 stones by a vertical mortar line. There are 11 lines, if one includes the mortar joint as the vertical / noon line. The lines RHS are badly eroded.
GLP noted that this dial is of particular interest as the angle of the lines suggest that it may be an early Scientific Dial. Comparing the lines with the correct angles for the latitude only one of the lines is more than 4º out. A further even more technical conclusion is that to function this dial would have needed a gnomon at an angle of 39º to the wall. This evidences an advance from earlier dials where the gnomon was simply inserted into its hole straight rather than angled.
St Andrew . Yetminster . Dorset – Scratch Dial 2St Andrew . Yetminster . Dorset – Scratch Dial 2
CLOCK † The historic faceless pendulum clock (1683) is being restored at the moment. I am writing the day after the Queen’s death, and by coincidence the clock has a specific significance: The Clock carillon plays the National Anthem at 3-hourly intervals. This dates from 1897 when it was installed by local benefactors for Queen Victoria’s Diamond Jubilee, and is very rare, and possibly unique. For the Platinum Jubilee of HM The Queen this year, the carillon was operated manually to ring out as part of our Jubilee Celebrations.
NOTES † 10 ‘formy’ Consecration Crosses in sunk round panels on external wall-facesBHO (locations specified); C10 Saxon cross shaft fragment; faceless clock of interest; good hunky punks. Links with Robert Boyle (chemistry, founder of the school) and Benjamin Jesty (smallpox); quite a lot of external graffiti – initials, dates and some Marian (‘witch’) marks
St Andrew . Yetminster . Dorset – Hunky PunksSt Andrew . Yetminster . Dorset – Consecration Crosses
St Andrew . Yetminster . Dorset – Graffiti and a Marian (ritual protection) mark. The 3 initialled and dated marks are likely to be cut by masons who did work on the church in the 1830s (cf Melbury Osmond)
St Andrew Yetminster – the detailed BSS records for the scratch dials
